| POSITION | REAR MOTOR | |
| CORE DATA | Wheel Size(inch) | 20/22/24/26/700C/28/29 |
| Construction | Brushless Gearless | |
| Rated Voltage(DCV) | 24/36/48 | |
| WINDING | 6T*9W | |
| n0(Rpm) | 400/520±10 | |
| magnet size | 27*2.3/27*3 | |
| Rated Power(W) | 180W-350W | |
| nT(Rpm) | 255 | |
| Max Torque(n.m) | 15-20 | |
| hall sensor | 1 | |
| Efficiency(%) | ≥80% | |
| surface color | Black | |
| Weight(kg) | 3 kg | |
| reduction ratio | 1.4.4 | |
| Noise Grade(db) | ＜50 | |
| Mounting Parameters | Brake | V/Disc brake |
| Cable Length (mm²), Connection Type | Left connection 1.5mm² | |
| Spoke Specification | 36H*12G | |
